Three-phase Blower Motor
The Three-phase Blower Motor adopts Class F insulation, high heat resistance temperature, strong impact resistance and long service life of insulation.
.
Introduction
The three-phase blower motor is a powerful and high-performance motor designed for industrial and commercial applications. It is designed to drive various types of air blowers, such as centrifugal blowers, axial blowers, and mixed-flow blowers. This motor is characterized by its high efficiency, reliability, and durability, making it ideal for a wide range of applications, from HVAC systems to industrial ventilation and exhaust systems.
Features and Benefits
The following are some of the key features and benefits of the three-phase blower motor:
1. High Efficiency
The three-phase blower motor is designed to operate at high efficiency, which means it can drive the air blower with less energy consumption. This translates to lower operating costs and higher savings for the user.
2. High Power Density
The motor has a high power density, which means it can deliver high torque and high speed even in a compact size. This makes it ideal for applications where space is limited.
3. High Reliability
The motor is designed to operate reliably in harsh and demanding conditions, including high temperature, high moisture, and high humidity. It has a robust construction and a long service life, which translates to lower maintenance costs and higher uptime for the user.
4. Smooth Operation
The three-phase blower motor is designed to operate smoothly and quietly, which means it can provide efficient and comfortable air flow without creating noise and vibration that can affect the user's experience.
5. Easy Installation
The motor is designed to be easy to install, with a standard mounting flange and wiring configuration that makes it compatible with various types of blowers and systems. This reduces the installation time and cost for the user.
Applications
The following are some of the typical applications of the three-phase blower motor:
1. Industrial Ventilation and Exhaust Systems
The motor is ideal for driving centrifugal blowers and axial blowers in industrial ventilation and exhaust systems, where it can provide efficient and reliable air flow for controlling temperature, humidity, and particulate matter.
2. HVAC Systems
The motor can be used in various types of HVAC systems, including air handlers, rooftop units, and exhaust fans, where it can provide efficient and comfortable air flow for heating, cooling, and ventilation.
3. Dust Collection Systems
The motor can be used in dust collection systems, where it can drive centrifugal and axial blowers to capture and remove dust and other airborne particles from the air.
4. Energy Recovery Systems
The motor can be used in energy recovery systems, where it can drive axial and mixed-flow blowers to extract heat from the exhaust air and transfer it to the intake air, thus reducing the energy consumption of the system.
Conclusion
The three-phase blower motor is a versatile and reliable motor that can provide efficient and high-performance operation in a wide range of industrial and commercial applications. Its high efficiency, reliability, durability, smooth operation, and easy installation make it an ideal choice for anyone looking for a high-quality motor to drive their air blowers. If you're interested in learning more about this product, please don't hesitate to contact us for more information.
Product Characteristics of Three-phase Blower Motor:
1. Three-phase Blower Motor Suitable for The Following Various Working Conditions:
Industrial machinery, plastic machinery, printing machinery, photo-engraving, electrical equipment, medical equipment, various burners, boilers, environmental aquaculture, etc.
Conditions of Use of Three-phase Blower Motor:
● The altitude does not exceed 1000m; (more than 1000m altitude, belongs to the plateau motor, can be customized)
● The maximum ambient temperature does not exceed 40℃
● The minimum ambient temperature does not exceed -15℃
Technical Data of Three-phase Blower Motor:
Type | Output | Rated current | Speed (r/min) | EFF. | P.F. | Ts/Tn | Tmax/Tn | Is/A | ||
220V | 230V | 240V | ||||||||
711 -2 | 0.18 | 1.89 | 1.81 | 1.74 | 2800 | 60 | 0.72 | 3 | 1.8 | 12 |
712-2 | 0.25 | 2.4 | 2.3 | 2.2 | 2800 | 64 | 0.74 | 3 | 1.8 | 15 |
801-2 | 0.37 | 3.36 | 3.21 | 3.08 | 2800 | 65 | 0.77 | 2.8 | 1.8 | 21 |
802-2 | 0.55 | 4.65 | 4.45 | 4.27 | 2800 | 68 | 0.79 | 2.8 | 1.8 | 29 |
90S-2 | 0.75 | 6.09 | 5.82 | 5.58 | 2800 | 70 | 0.8 | 2.5 | 1.8 | 37 |
90L-2 | 1.1 | 8.68 | 8.3 | 7.96 | 2800 | 72 | 0.8 | 2.5 | 1.8 | 60 |
100L1-2 | 1.5 | 114 | 10.9 | 10.4 | 2800 | 74 | 0.81 | 2.5 | 1.8 | 80 |
100L2-2 | 2.2 | 16.5 | 15.7 | 15.1 | 2800 | 75 | 0.81 | 2.2 | 1.8 | 120 |
112M-2 | 3 | 21.9 | 20.9 | 20.1 | 2800 | 76 | 0.82 | 2.2 | 1.8 | 150 |
132S-2 | 3.7 | 26.6 | 25.5 | 24.4 | 2800 | 77 | 0.82 | 2.2 | 1.8 | 175 |
71 1-4 | 0.12 | 1.88 | 1.8 | 1.72 | 1400 | 50 | 0.58 | 3 | 1.8 | 9 |
712-4 | 0.18 | 2.49 | 2.38 | 2.28 | 1400 | 53 | 0.62 | 2.8 | 1.8 | 12 |
801-4 | 0.25 | 3.11 | 2.97 | 2.85 | 1400 | 58 | 0.63 | 2.8 | 1.8 | 15 |
802-4 | 0.37 | 4.24 | 4.05 | 3.89 | 1400 | 62 | 0.64 | 2.5 | 1.8 | 21 |
90S-4 | 0.55 | 5.49 | 5.25 | 5.03 | 1400 | 66 | 0.69 | 2.5 | 1.8 | 29 |
90L-4 | 0.75 | 6.87 | 6.57 | 6.3 | 1400 | 68 | 0.73 | 2.5 | 1.8 | 37 |
Features of Three-phase Blower Motor :
● The AC Blower has little mechanical wear during operation and has a long service life.
● The AC Blower adopts a wide frequency and wide voltage motor, and the operation is stable.
● The air inlet and outlet of the AC Blower are equipped with sound-absorbing cotton to reduce the wind noise generated by the fan, that is, to achieve low noise and not cause trouble to the surrounding residents.
● AC Blowers are durable and easy to maintain.
SIVO MOTOR Also Produces Other Motors:
YY Capacitor Running Single-phase Induction Motor、YL Two Capacitor Single-phase Induction Motor、YC Capacitor-start Single-phase Induction Motor、Single Phase Electric Motors、Asynchronous Electric Motor、Single Phase Asynchronous PSC Motor for Air Conditioner、Induction Motor Single Phase、Single Phase Asynchronous Motor for Air Conditioner
Zhejiang Fangyuan Sifu Mechanical And Electrical Co., Ltd. is a high-tech enterprise focusing on motor R&D, manufacturing and sales. It is one of the core enterprises in the manufacturing sector of China's top 500 private enterprises, Fangyuan Group. The company's main products include cast iron single and three phase asynchronous motor series, aluminum housing single and three phase asynchronous motor series, fan special motor series, frequency conversion motor series, permanent magnet DC motor series and so on. Mainly used in water pump power, fan power, machine equipment power, agricultural machinery power, new energy vehicle power, marine equipment power and other fields.
Zhejiang Fangyuan Sifu Mechanical And Electrical Co., Ltd. has advanced research and development equipment and manufacturing equipment, advanced motor type laboratory and fan testing laboratory. The motor type laboratory can measure 0.06kW-315kW three-phase asynchronous motors, single-phase asynchronous motors and permanent magnet variable frequency servo motors. The wind chamber laboratory can detect various types of fans with an air volume below 50,000m3.
