Vertical Pump Motor
The Vertical Pump Motor mainly used in multi-stage pump motors, multi-stage pumps are commonly used in machinery, mining, light industry, medicine and food.
Vertical Pump Motor Product Introduction
Are you looking for a reliable and high-performance vertical pump motor for your water system? Look no further as we introduce our quality Vertical Pump Motor, designed and manufactured in China. With our years of expertise, we bring you the best product that guarantees efficiency, durability, and utmost satisfaction.
Our Vertical Pump Motor is a key component in many different applications, including water supply systems, agricultural fields, and industrial uses. This motor is designed to operate in vertical and water-immersed conditions, making it an ideal choice for a wide range of water system applications. Our product is perfect for various types of pumps such as centrifugal, submersible, and deep well pumps.
Our product is engineered to deliver superior performance with minimum energy consumption. Our vertical pump motor features a compact design with high-density copper wire and premium-quality bearings, ensuring maximum electrical efficiency and stability. Our motor is a great investment for merchants who want to save on electricity without compromising functionality.
Our pump motor has been meticulously designed to withstand harsh environmental conditions with its durable structure, featuring a robust cast iron casing and high-strength stainless steel shaft. It has been designed to operate seamlessly under extreme loads and variable frequency drives (VFD). Our product is also equipped with different types of NRV and protection housings that safeguard the motor from short-circuiting, voltage fluctuations, hydraulic surges, and mechanical overloads.
Our product is easy to install, operate, and maintain, with little or no specialized technical knowledge required. Our team of professional engineers and technicians are available around the clock to provide technical support and after-sales services. We provide a wide range of customization options to meet the specific needs of different customers.
In terms of safety, our Vertical Pump Motor is CE and CCC certified with built-in safety features that make it suitable for various applications. We have tested and validated our product to meet international standards for quality, safety, and environmental protection.
Our product has been extensively used in various water system applications such as agricultural irrigation, public water supply, deep-borehole pumps, bore-well pumps, and oil refineries. With proven performance and unrivaled reliability, our vertical pump motor is the perfect solution for merchants who value stability, safety, and functionality.
With our competitive pricing and reliable product quality, merchants can rest assured that they are investing in a top-of-the-line product that has been tested and validated under the most demanding conditions. Our Vertical Pump Motor is a great choice for customers who want to maximize their productivity while minimizing their energy consumption.
In conclusion, our vertical pump motor is an excellent product that combines quality, efficiency, and durability. Our product is a market leader in the water system industry, providing merchants with a reliable and efficient tool to meet their needs. With our product, merchants can ensure that their water system will run efficiently, safely, and reliably for years to come. Get in touch today to place your order and let us help you boost your productivity!
Product Characteristics of Vertical Pump Motor:
1. Vertical multistage pump for various working conditions:
Mainly used in multi-stage pump motors, multi-stage pumps are commonly used in machinery, mining, light industry, medicine and food.
2. The motor core adopts cold-rolled silicon steel sheet, F-class insulation, high heat resistance temperature, strong impact resistance and long service life of insulation.
3. The Vertical Pump Motor casing is made of die-cast aluminum alloy. The motor has good heat dissipation, stable operation, low noise, low vibration, stable performance, safe and reliable, and convenient installation.
4. The Vertical Pump Motor efficiency reaches the level of high efficiency and high efficiency, and the energy saving effect is good. It is an ideal energy- saving product.
Main Technical Parameters of Vertical Pump Motor:
● The altitude does not exceed 1000m; (more than 1000m altitude, belongs to the plateau motor, can be customized)
● The maximum ambient temperature does not exceed 40℃ (>40℃ can be customized)
● The minimum ambient temperature does not exceed -15℃ (<-15℃ can be customized)
● S1 working system
● The power supply voltage fluctuation does not exceed ±5% (10% is allowed for short time); the frequency fluctuation does not exceed ±2%
● Insulation class F
● Protection level: IP54, IP55
● Cooling method: IC411
Technical Data of Vertical Pump Motor (IE3, Speed 3000rpm 2-pole 50Hz):
Type | Rated Output | Rated Speed | Efficiency | Power factor | Rated current A | Rated Torque | Ts/Tn | Tmax/Tn | Is/In | Weight kg | ||
380V | 400V | 415V | ||||||||||
SGY3-71M1-2 | 0.37 | 2750 | 73.8 | 0.81 | 0.94 | 0.89 | 0.86 | 1.28 | 2.3 | 2.2 | 7 | 8 |
SGY3-71 M2-2 | 0.55 | 2750 | 77.8 | 0.82 | 1.31 | 1.24 | 1.2 | 1.91 | 2.3 | 2.3 | 7.0 | 9 |
SGY3-80M1-2 | 0.75 | 2880 | 80.7 | 0.82 | 1.72 | 1.64 | 1.58 | 2.49 | 2.3 | 2.3 | 7.0 | 11.5 |
SGY3-80M2-2 | 1.1 | 2880 | 82.7 | 0.83 | 2.43 | 2.31 | 2.23 | 3.65 | 2.2 | 2.3 | 7.6 | 12.5 |
SGY3-90S-2 | 1.5 | 2895 | 84.2 | 0.84 | 3.22 | 3.06 | 2.95 | 4.95 | 2.2 | 2.3 | 7.9 | 18 |
SGY3-90L-2 | 2.2 | 2895 | 85.9 | 0.85 | 4.58 | 4.35 | 4.19 | 7.26 | 2.2 | 2.3 | 7.9 | 20 |
SGY3-100L-2 | 3 | 2895 | 87.1 | 0.87 | 6.02 | 5.71 | 5.51 | 9.9 | 2.2 | 2.3 | 8.5 | 24 |
SGY3-11 2M-2 | 4 | 2905 | 88.1 | 0.88 | 7.84 | 7.45 | 7.1 8 | 13.1 | 2.2 | 2.3 | 8.5 | 30 |
SGY3-132S1-2 | 5.5 | 293 0 | 89.2 | 0.88 | 10.6 | 10.1 | 9.75 | 17.9 | 2 | 2.3 | 8.5 | 53 |
SGY3-132S2-2 | 7.5 | 293 0 | 90.1 | 0.88 | 14.4 | 13.7 | 13.2 | 24.4 | 2 | 2.3 | 8.5 | 71 |
SGY3-1 60M1-2 | 11 | 2945 | 91.2 | 0.89 | 20.6 | 19.6 | 18.9 | 35.7 | 2 | 2.3 | 8.5 | 1 12 |
SGY3-1 60M2-2 | 15 | 2945 | 91.9 | 0.89 | 27.9 | 26.5 | 25.5 | 48.6 | 2 | 2.3 | 8.5 | 132 |
SGY3-1 60L-2 | 18.5 | 2940 | 92.4 | 0.89 | 34.2 | 32.5 | 31.3 | 60.1 | 2 | 2.3 | 8.5 | 150 |
SIVO Motor Also Produces Other Motors:
Three Phase AC Induction Motor、3 Phase AC Gear Motor、Brushless AC Motor、220V Ac Motor
Zhejiang Fangyuan Sifu Mechanical And Electrical Co., Ltd. is a high-tech enterprise focusing on motor R&D, manufacturing and sales. It is one of the core enterprises in the manufacturing sector of China's top 500 private enterprises, Fangyuan Group. The company's main products include cast iron single and three phase asynchronous motor series, aluminum housing single and three phase asynchronous motor series, fan special motor series, frequency conversion motor series, permanent magnet DC motor series and so on. Mainly used in water pump power, fan power, machine equipment power, agricultural machinery power, new energy vehicle power, marine equipment power and other fields.
Why choose us?
- Our team of skilled technicians and engineers are passionate about what they do, and have the expertise and experience necessary to provide unmatched Pump Motor products and support.
- We welcome you to definitely inquire us by simply call or mail and hope to develop a prosperous and cooperative connection.
- Our Pump Motor products are rigorously tested for quality and performance, ensuring that every product meets our strict standards.
- Our company faces the production of Vertical Pump Motor with hard-working and honest working methods and attitudes. Our team maintains a clear and definite production direction and customer needs during the work process. We hope to achieve results step by step under the guidance of advanced production concepts through scientific and logical working methods.
- Our extensive knowledge and experience in the industry enable us to provide expert advice and support to our clients, helping them to achieve their goals.
- In the future, we hope to continue to provide customers with the best and most innovative Vertical Pump Motor and continue to create new brilliance.
- Our team of skilled technicians and engineers work tirelessly to ensure that our Pump Motor products meet and exceed your expectations.
- Our company has accumulated many years of Vertical Pump Motor scientific research and production experience, strong technical force, complete testing methods, reliable product quality, and warm and thoughtful service.
- Our Pump Motor products are renowned for their durability, longevity, and optimal performance.
- We have a strong product professional design and development team with rich professional design and research and development experience, and can provide a complete set of development services according to customer requirements.
