AC 50Hz Aluminum Wire Winding Box Fan Motor for 8 9 10 16 20 Inch Floor Fan

Name: China Custom Box Fan Motor Manufacturers Suppliers Factory - Wholesale Service - SIVO
Brand: SIVO
SKU: 166925358

Single Phase Asynchronous Motor for Air Conditioner for Air Conditioner has high reliability, easy installation and simple control

Send Inquiry

The company will continue to forge ahead as always, move towards a higher goal, and make its due contribution to the rational use of Axial Fan Motor, High Efficiency Electric Motor, IE3 Premium Motor for mankind. We'll generally welcome guests from all over the world to our business to create business relations with us. With the increasing competition, brand reputation has become a huge potential competitive advantage.

Main Technical Parameters of Box Fan Motor:

● The altitude does not exceed 1000m; (more than 1000m altitude, belongs to the plateau motor, can be customized)

● The maximum ambient temperature does not exceed 40℃

● The minimum ambient temperature does not exceed -15℃

● S1 working system

● The power supply voltage fluctuation does not exceed ±5% (10% is allowed for short time); the frequency fluctuation does not exceed ±2%

● Insulation class F

● Protection level: IP54, IP55

● Cooling method: IC411

Technical Data of Box Fan Motor:

Type	Rated Output kW	Rated Speed min^-1	Rated current A			Rated Torque Nm	Ts/Tn	Tmax/Tn	Is/In
Type	Rated Output kW	Rated Speed min^-1	380V	400V	415V	Rated Torque Nm	Ts/Tn	Tmax/Tn	Is/In
SAL1-90S-8	0.37	670	1.85	1.76	1.7	5.27	1.8	1.9	4
SAL1-100L1-8	0.75	680	2.78	2.64	2.54	10.5	1.8	2	6.5
SAL1-100L2-8	1.1	685	3.42	3.25	3.13	15.3	1.8	2	6.5
SAL1-100L3-8	1.5	690	4.64	4.41	4.25	24.9	1.8	2	5.5
SAL1-112M-8	1.8	690	5.07	4.81	4.64	24.9	1.8	2	6.6
SAL1-112L-8	2.2	690	5.5	5.23	5.08	30.4	1.8	2	5.5

Type	Rated Output kW	Rated Speed min^-1	Rated current A			Rated Torque Nm	Ts/Tn	Tmax/Tn	Is/In
Type	Rated Output kW	Rated Speed min^-1	380V	400V	415V	Rated Torque Nm	Ts/Tn	Tmax/Tn	Is/In
SAL1-90S1-6	0.25	850	1.07	1.02	0.98	2.81	1.9	2	4
SAL1-90S2-6	0.37	885	1.35	1.28	1.23	3.99	1.9	2	4.7

SIVO MOTOR also produces other motors:

Air Conditioner Fan Motor、Cooling Fan Motor、Cooling Fan Electric Motor、Single Phase cooler motor、Three-phase cooler motor、Air Cooler Motor

Cooler Fan Motor、Evaporative Cooler Motor、Air cooler fan motor、High speed cooler motor

Zhejiang Fangyuan Sifu Mechanical and Electrical Co., Ltd. is a high-tech enterprise focusing on motor R&D, manufacturing and sales. It is one of the core enterprises in the manufacturing sector of China's top 500 private enterprises, Fangyuan Group. The company's main products include cast iron single and three phase asynchronous motor series, aluminum housing single and three phase asynchronous motor series, fan special motor series, frequency conversion motor series, permanent magnet DC motor series and so on. Mainly used in water pump power, fan power, machine equipment power, agricultural machinery power, new energy vehicle power, marine equipment power and other fields.

We develop more innovative technologies and products that help improve the customer experience and inject a strong force into this AC 50Hz Aluminum Wire Winding Box Fan Motor for 8 9 10 16 20 Inch Floor Fan industry. We uphold the core values of honesty and truth-seeking, innovation and harmony, and pursue the business philosophy of green intelligence, safety and efficiency. We will continue to satisfy customers as our business philosophy, and follow the path of scientific development to achieve mutual benefit and win-win results with customers.
