Xiushi CH28 mm Herizontal Type Three Phase Gear Motor

Name: China Single Phase Asynchronous Motor for Air Conditioner Manufacturers Suppliers Factory
Brand: SIVO
SKU: 166925134

Asynchronous Electric Motor also known as induction motor, is an AC motor that generates electromagnetic torque by the interaction between air gap rotating magnetic field and rotor winding induced current, so as to realize the conversion of electromechanical energy into mechanical energy.

Send Inquiry

To achieve our goals, we work with our customers to develop and optimize Single Phase Asynchronous Motor, Transformer Cooling Fan Motor, Air Cooler Motor and services so as to create new values for them. We continue to carry forward the enterprise spirit of "truth-seeking and innovation, unity and progress". The tenet of our company: honesty is the cornerstone, quality is the guarantee and win-win is the goal.

Introduction of Asynchronous Electric Motor:

● Asynchronous Electric Motor also known as induction motor, is an AC motor that generates electromagnetic torque by the interaction between air gap rotating magnetic field and rotor winding induced current, so as to realize the conversion of electromechanical energy into mechanical energy.

●Three phase asynchronous motors are mainly used as motors to drive various production machinery, such as fans, pumps, compressors, machine tools, light industry and mining machinery, threshers and crushers in agricultural production, processing machinery in agricultural and sideline products, etc. The utility model has the advantages of simple structure, easy manufacture, low price, reliable operation, durability, high operation efficiency and applicable working characteristics.

Features of Asynchronous Electric Motor:

1. Asynchronous Electric Motor is suitable for small machinery such as refrigerator, pump, fan, small machine tool, reducer, medical equipment, agricultural and sideline products processing and household appliances, especially for occasions with only single-phase current.

2. Installation dimensions and power levels meet GB, DIN and IEC standards.

3. Ultra-high efficiency motor, the efficiency reaches IEC 60034- 30:2014 IE 4 or IE4 and GB 18613-2020 energy efficiency level 3 or 2.

4. The motor core is cold-rolled silicon steel sheet, F-grade insulation, high heat-resistant temperature, strong impact resistance, long insulation life.

5. The motor shell is made of aluminum alloy or cast iron with stable structure, low vibration, low noise, stable performance, safety and reliability.

Technical Data of Asynchronous Electric Motor:

Type	Output	Rated current			Speed (r/min)	EFF.	P.F.	Ts/Tn	Tmax/Tn	Is/A
Type	kW	A			Speed (r/min)	(%)	P.F.	Ts/Tn	Tmax/Tn	Is/A
		220V	230V	240V
711 -2	0.18	1.89	1.81	1.74	2800	60	0.72	3	1.8	12
712-2	0.25	2.4	2.3	2.2	2800	64	0.74	3	1.8	15
801-2	0.37	3.36	3.21	3.08	2800	65	0.77	2.8	1.8	21
802-2	0.55	4.65	4.45	4.27	2800	68	0.79	2.8	1.8	29
90S-2	0.75	6.09	5.82	5.58	2800	70	0.8	2.5	1.8	37
90L-2	1.1	8.68	8.3	7.96	2800	72	0.8	2.5	1.8	60
100L1-2	1.5	114	10.9	10.4	2800	74	0.81	2.5	1.8	80
100L2-2	2.2	16.5	15.7	15.1	2800	75	0.81	2.2	1.8	120
112M-2	3	21.9	20.9	20.1	2800	76	0.82	2.2	1.8	150
132S-2	3.7	26.6	25.5	24.4	2800	77	0.82	2.2	1.8	175
71 1-4	0.12	1.88	1.8	1.72	1400	50	0.58	3	1.8	9
712-4	0.18	2.49	2.38	2.28	1400	53	0.62	2.8	1.8	12
801-4	0.25	3.11	2.97	2.85	1400	58	0.63	2.8	1.8	15
802-4	0.37	4.24	4.05	3.89	1400	62	0.64	2.5	1.8	21
90S-4	0.55	5.49	5.25	5.03	1400	66	0.69	2.5	1.8	29
90L-4	0.75	6.87	6.57	6.3	1400	68	0.73	2.5	1.8	37
100L1-4	1.1	9.52	9.1 0	8.72	1400	71	0.74	2.5	1.8	60
100L2-4	1.5	12.5	11.9	11.4	1400	73	0.75	2.5	1.8	80
112M-4	2.2	1 7.8	17	16.3	1400	74	0.76	2.2	1.8	120
132S-4	3	23.6	22.6	21.6	1400	75	0.77	2.2	1.8	150
132M-4	3.7	28	26.8	25.7	1400	76	0.79	2.2	1.8	175

SIVO Motor Also Produces Other Motors:

Permanent Magnet DC Motor、Permanent Magnet Electric Motor、Single Phase PMSM Motor、Three-phase PMSM Motor、Interior Permanent Magnet Synchronous Motor

Q: When can I get the quotation?

A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us so that we will regard your inquiry priority.

Q: How can I get a sample to check your quality?

A: After price confirmation, you can require for samples to check our quality.

If you need the samples, we would like to send sample from our Chinese factory.
